GPON ONT (4GE+WiFi 5+1USB ONT) (V2804AC-Z) (Dual Mode GPON/EPON)
Original price was: ₹4,130.00.₹1,416.00Current price is: ₹1,416.00.
66% Off
Out of stock
V2804AC-Z (4GE+WiFi5+CATV+USB3.0 XPON ONT) is a broadband access device specially designed to meet the needs of fixed network operators for FTTH and triple play services.
The ONT is based on high-performance chip solutions, supports XPON dual-mode technology (EPON and GPON), and also supports IEEE802.11b/g/n/ac WIFI technology and other Layer 2/Layer 3 functions, providing data service for carrier-grade FTTH applications. In addition, the ONT also supports the OAM/OMCI protocol, and we can configure or manage various services of the ONT on the VSOL OLT.
The ONT has high reliability, is easy to manage and maintain, and has QoS guarantees for various services. It conforms to a series of international technical standards such as IEEE802.3ah and ITU-T G.984.
The ONT is based on high-performance chip solutions, supports XPON dual-mode technology (EPON and GPON), and also supports IEEE802.11b/g/n/ac WIFI technology and other Layer 2/Layer 3 functions, providing data service for carrier-grade FTTH applications. In addition, the ONT also supports the OAM/OMCI protocol, and we can configure or manage various services of the ONT on the VSOL OLT.
The ONT has high reliability, is easy to manage and maintain, and has QoS guarantees for various services. It conforms to a series of international technical standards such as IEEE802.3ah and ITU-T G.984.
- Material: ABS Plastic
- Size: 205mm×140mm×37mm(L×W×H)
- Weight: 0.34Kg
No cancellation , no refund available
Out of stock
Description
| ○ Hardware Parameter | |
| Dimension | 205mm×140mm×37mm(L×W×H) |
| Net weight | 0.34Kg |
| Operating condition | Operating temp: 0 ~ +50°C Operating humidity: 5 ~ 90% (non-condensed) |
| Storing condition | Storing temp: -30 ~ +75°C Storing humidity: 5 ~ 90% (non-condensed) |
| Power adapter | DC 12V, 1/1.5A, external AC-DC power adaptor |
| Power supply | ≤10W |
| Interfaces | 4GE+WiFi5+USB 3.0 |
| Indicators | PWR, PON, LOS, WAN, ETH1~ETH4, 2.4Ghz WiFi, 5Ghz WiFi, WPS, USB |
| ○ Interface parameter | |
| PON interface |
|
| WiFi interface |
|
| LAN interface | 4*GE, Auto-negotiation, RJ45 ports |
| USB interface | USB 3.0 for Shared Storage/Printer |
| ○ Function Data | |
| XPON mode | Dual mode , can access EPON/GPON OLTs(HUAWEI,ZTE,FiberHome, etc.) |
| Connect mdoe | Routing Mode |
| WiFi |
|
| Firewall | DDOS, Filtering Based on ACL/MAC/URL |
| Layer2 | 802.1D & 802.1ad bridge, 802.1p Cos,802.1Q VLAN |
| Layer3 | IPv4/IPv6 , DHCP Client/Server , PPPoE , NAT , DMZ , DDNS |
| Multicast | IGMP v1/v2/v3 , IGMP snooping |
| Security | Flow & Storm control, Loop Detection |
| O&M | WEB/TELNET/OAM/OMCI, Support private OAM/OMCI protocol and Unified network management of VSOL OLT |
Additional information
| Weight | 0.800 kg |
|---|
